Powertrain Industries 3304-262

Powertrain Industries 3304-262 Quantity in Basket: None
Code: PTI-3304-262
Price: $40.18

1 In Stock



Quantity:

End Yoke - Splined Bore
1330 series, 1.146x26 spline, 1.496 hub diameter
Commonly used as the center yoke in 2 piece Toyota Tacoma driveshaft


The following parts may be used as alternates for this part:

Dana/Spicer 2-4-02009 -- In Stock, Our Price: $ 41.93
Dana/Spicer 5002009 -- Obsolete



U-Joint Series     1330
Spline Major Diameter     1.146
Spline Count     26.000
Spline Type     Involute
Spline Pressure Angle
Ground Hub Diameter   R   1.492
Length Thru Bore   Q   1.973
Centerline of Joint to End of Spline   S   3.465
Universal Joint Retaining Width   E   3.625
Universal Joint Bearing Diameter   D   1.062
Counterbore Depth     0.000
Joint Angle     0.000
Style     Snap Ring
Compatible U-Joint Kits     SPI-5-213X,SPI-5-1330X,SPI-SPL25-1X
U-Bolt or Strap Assembly
Bare Yoke part number (if assembly - included)
Slinger Part Number (if assembly - included)     SPI-5004797
Notes     Coupling shaft yoke; Hub diameter not ground
Cast/Forged     Cast
