Northern Drivetrain 00149
|
| |
|
Quantity in Basket:
None
Code: NDT-00149
Price: $158.31
1 In Stock
|
| |
Tube Shaft
Ø1.750x16 spline, Ø2.500 X .250 Tube
|
This slip stub / tube shaft is commonly used with our NDT-3-3-5191KX 1480 series slip yoke, or any standard 1550 series 16 spline slip yoke. The standard Ø1-9/16"x16 spline 1480 slip stub is the known weak link for any power/racing application. This stub allows for a stronger, heavy wall driveshaft suitable for high horsepower rock rigs or any other application that can benefit from a heavy wall driveshaft.
This part is a member of the following categories:
Search by Category * Driveshaft Components * Tube Shafts * Ø1.750 - 16 Spline
| Spline Major Diameter |
|
1.750 |
| Spline Count |
|
16.000 |
| Spline Type |
|
Parallel |
| Tube Diameter and Wall Size |
|
2.500 X .250 |
| End of Spline to Weld |
K |
6.500 |
| Length of Spline |
L |
3.000 |
| End of Spline to Radius |
R |
5.812 |
| Notes |
|
|
|
| |
|
