*** Fits early GM NP205 transfer case with 1-1/4 x 10 coarse spline ***
|
Northern Drivetrain 00157
|
| |
|
Quantity in Basket:
None
Code: NDT-00157
Price: $198.06
3 In Stock
|
| |
Companion Flange - Splined Bore
1330 series, Ø1.250-10 spline
4x7/16-14 Tapped Holes on 4.25BC, Ø3.125-M pilot
|
This flange was designed to run the later model Saginaw pattern front driveshafts on the early GM NP205 transfer case 10 spline front outputs. However, CV options are not limited to the 3R CV assembly. CV components are available to fit 1310, 1330, 1350, and 1410 series CV's to this flange as well.
This part is a member of the following categories:
Search by Application * Search by Transfer Case * New Process * 205
Search by Category * Companion Flanges * Splined Bore * 10 Splines * Ø1.250 - 10 Spline
| U-Joint Series |
|
1330 |
| Spline Major Diameter |
D |
1.250 |
| Spline Count |
|
10.000 |
| Spline Type |
|
Spline |
| Pilot Bore Diameter |
C |
3.125-M |
| Bolt Circle Diameter |
B |
4.250 |
Bolt Circle Hole Diameter
(D = Drilled, T = Tapped) |
|
.438 T |
| Number of Holes |
|
4.000 |
| Brake Pilot Diameter |
|
0.000 |
| Ground Hub Diameter |
E |
1.750 |
| Length Thru Bore |
F |
2.000 |
| Flange Face to End of Hub |
G |
2.125 |
| Bare Flange Part Number (if assembly) |
|
|
| Slinger Part Number (if assembly) |
|
|
| Notes |
|
Square bolt pattern |
|
