Neapco N2-4-583
|
|
|
Quantity in Basket:
None
Code: NEA-N2-4-583
Price: $62.47
2 In Stock
|
|
End Yoke - Round Bore 1310 series, Ø0.875 Bore w/0.25 keyway, Ø2.000 hub diameter
|
The following parts may be used as alternates for this part:
Dana/Spicer 2-4-583
Rockwell/Meritor 131N-4-583
This part is a member of the following categories:
Search by Category * End Yokes * Round Bore
General Design Type |
|
Round Bore |
U-Joint Series |
|
1310 |
Bore Diameter |
P |
0.875 |
SAE Keyway Width |
X |
0.250 |
Hub Diameter |
R |
2.000 |
Universal Joint Retaining Width |
E |
3.469 |
Universal Joint Bearing Diameter |
D |
1.062 |
Length Thru Bore |
Q |
1.625 |
Centerline of Joint to End of Hub |
S |
2.563 |
Set Screw Thread |
|
0.375-16 |
Keyway Location |
|
|
Set Screw Location Clock position viewed at Hub End and Keyway at 12 |
W |
|
Joint Angle |
|
17.000 |
Style |
|
Snap Ring |
Compatible U-Joint Kits |
|
SPI-5-153X,SPI-5-1310X,SPI-5-1310-1X |
U-Bolt or Strap Assembly |
|
|
Notes |
|
|
Cast/Forged |
|
|
This part is used in the following assemblies or kits:
This part contains the following parts:
