Neapco N2-53-501
|
| |
|
Quantity in Basket:
None
Code: NEA-N2-53-501
Price: $123.05
2 In Stock
|
| |
Splined Midship Tube Shaft
1.375x16 spline, Ø3.000 X .083 tube
|
The following parts may be used as alternates for this part:
Dana/Spicer 2-53-501
Rockwell/Meritor 121N-53-501
Rockwell/Meritor 131N-53-501
This part is a member of the following categories:
Search by Category * Driveshaft Components * Splined Midship Tube Shafts * 1.375 - 16 Spline
| General Design Type |
|
For use with Outboard Slip Yokes |
| Spline Major Diameter |
D |
1.375 |
| Spline Count |
|
16.000 |
| Spline Type |
|
|
| Bearing Diameter |
C |
1.378 |
| Tube Diameter and Wall Size |
|
3.000 X .083 |
| End of Spline to Bearing Shoulder |
Y |
6.938 |
| End of Spline to Point of Weld |
K |
8.000 |
| Length of Spline |
L |
5.406 |
| Thread Size |
|
|
| Shoulder Diameter |
B |
1.688 |
| Length of Shoulder |
G |
0.812 |
| Notes |
|
|
This part is used in the following assemblies or kits:
This part contains the following parts:
|
| |
|
