Neapco N3-28-1411X
|
| |
|
Quantity in Basket:
None
Code: NEA-N3-28-1411X
Price: $162.95
1 In Stock
|
| |
Ball Stud Tube Yoke
1410 series
non-greasable, Ø2.750 X .083 tube
|
This part is a member of the following categories:
Search by Category * Driveshaft Components * Tube Yokes * 1410
| U-Joint Series |
|
1410 |
| Universal Joint Retaining Width |
E |
4.188 |
| Universal Joint Bearing Diameter |
D |
1.188 |
| Compatible U-Joint Kits |
|
SPI-5-160X,SPI-5-1410X |
| Tube Diameter and Wall Size |
|
2.750 X .083 |
| Butt Diameter |
F |
2.594 |
| Centerline of Joint to Point of Weld |
K |
2.480 |
| Centerline of Joint to End of Ball Stud |
J |
0.000 |
| Ball Stud Length |
L |
0.000 |
| Ball Stud Diameter |
H |
0.500 |
| Max Joint Angle (double value for max CV assy angle) |
|
11.000 |
| Greasable |
|
No |
| Slinger/Seal part number (included) |
|
SPI-2-86-418 |
| Notes |
|
|
This part is used in the following assemblies or kits:
NEA-N924142HAG - Double Cardan CV Head
|
| |
|
