Neapco N5-53-141

Neapco N5-53-141 Quantity in Basket: None
Code: NEA-N5-53-141
Price: $120.86

1 In Stock





Quantity:

Splined Midship Tube Shaft
1.750x10 spline, Ø3.500 X .134 tube


The following parts may be used as alternates for this part:


This part is a member of the following categories:

Search by Category * Driveshaft Components * Splined Midship Tube Shafts * 1.750 - 10 Spline


General Design Type     Companion Flange or End Yoke Design
Spline Major Diameter   D   1.750
Spline Count     10.000
Spline Type
Bearing Diameter   C   1.772
Tube Diameter and Wall Size     3.500 X .134
End of Spline to Bearing Shoulder   Y   3.250
End of Spline to Point of Weld   K   4.344
Length of Spline   L   2.100
Thread Size     M-1.250-18
Shoulder Diameter   B   2.188
Length of Shoulder   G   0.813
Notes


This part is used in the following assemblies or kits:


This part contains the following parts:
