Neapco N6-1-1253-3
|
| |
|
Quantity in Basket:
None
Code: NEA-N6-1-1253-3
Price: $540.03
1 In Stock
|
| |
Companion Flange - Circular w/Straight Round Bore
1710 series, Ø2.750 Bore w/0.625 keyway
8xØ0.386 Holes, Ø7.750-F pilot
|
This part is a member of the following categories:
Search by Category * Companion Flanges * Circular with Straight Round Hole
| U-Joint Series |
|
1710 |
| Bore Diameter |
D |
2.750 |
| Keyway Size |
K |
0.625 |
| Flange Diameter |
A |
8.000 |
| Pilot Bore Diameter |
C |
7.750-F |
| Bolt Circle Diameter |
B |
7.250 |
Bolt Hole Diameter
(D = Drilled, T = Tapped) |
|
0.386-D |
| Number of Holes |
|
8.000 |
| Ground Hub Diameter |
E |
0.000 |
| Length Thru Bore |
F |
4.000 |
| Notes |
|
|
|
| |
|
