This part's status is Obsolete
.
|
Spicer 10-4-1131SX
|
| |
|
Quantity in Basket:
None
Code: SPI-10-4-1131SX
Price: $69.31
1 In Stock
|
| |
Steering Shaft Yoke
1310 series, Ø1.014x66 spline
|
| General Design Type |
|
Serrated Bore |
| U-Joint Series |
|
1310 |
| Spline Major Diameter |
|
1.014 |
| Spline Minor Diameter (Nominal) |
|
0.975 |
| Spline Type |
|
66 Based On 79 Spline |
| Bore Diameter |
|
|
| Keyway Size |
|
0.000 |
| Bolt Hole Diameter |
|
0.406 |
| |
|
1.970 |
| Centerline of Bolt Hole to End of Hub |
J |
0.380 |
| Top of Bolt Hole to Centerline of Spline |
L |
0.835 |
| Center of Bolt Hole to Center of Spline |
L1 |
0.000 |
| Centerline of Joint to End of Hub |
S |
2.340 |
| Universal Joint Retaining Width |
K |
1.500 |
| Universal Joint Bearing Diameter |
D |
0.938 |
| Compatible U-Joint Kits |
|
SPI-5-103X |
| Notes |
|
|
| Cast/Forged |
|
|
|
| |
|
