Spicer 2-2-03489
|
| |
|
Quantity in Basket:
None
Code: SPI-2-2-03489
Price: $106.26
1 In Stock
|
| |
Flange Yoke
1330 series, 4xØ.500 Holes on 4.750BC, Ø2.953F pilot
|
| Design Style |
|
Snap Ring Design |
| U-Joint Series |
|
1330 |
| Universal Joint Retaining Width |
|
3.875 |
| Universal Joint Bearing Diameter |
D |
1.062 |
| Flange Diameter |
A |
5.875 |
| Bolt Circle Diameter |
B |
4.750 |
| Horizontal Distance Between Holes (center to center) |
|
3.359 |
| Vertical Distance Between Holes (center to center) |
|
3.359 |
| Bolt Hole Diameter |
|
.500-D |
| Bolt Hole Quantity |
|
4.000 |
| Pilot Diameter (M-Male, F-Female) |
C |
2.953F |
| Centerline of Joint to Flange Face |
G |
1.730 |
| Compatible U-Joint Kits |
|
SPI-5-213X,SPI-5-1330X,SPI-SPL25-1X |
| |
|
0.000 |
| Notes |
|
12 mm bolt holes equally spaced. Part has hole thru ctr. |
| Cast/Forged |
|
|
Known Idenfiying Marks (Casting/Forging numbers, etc.):
| | Mark | | Location |
| |
C3-2-831
| |
In base of flange |
|
| |
|
