Spicer 2-4-7501-1X
|
| |
|
Quantity in Basket:
None
Code: SPI-2-4-7501-1X
Price: $26.84
|
| |
End Yoke Assy - Splined Bore
1310 series, Strap Style, Ø1.146x26 spline, Ø1.469 hub diameter
|
This part is a member of the following categories:
Search by Category * End Yokes * Splined Bore * 26 Splines * 1.146 - 26 Involute
| U-Joint Series |
|
1310 |
| Spline Major Diameter |
|
1.146 |
| Spline Count |
|
26.000 |
| Spline Type |
|
Involute |
| Spline Pressure Angle |
|
|
| Ground Hub Diameter |
R |
1.469 |
| Length Thru Bore |
Q |
1.484 |
| Centerline of Joint to End of Spline |
S |
3.500 |
| Universal Joint Retaining Width |
E |
3.219 |
| Universal Joint Bearing Diameter |
D |
1.062 |
| Counterbore Depth |
|
0.000 |
| Joint Angle |
|
0.000 |
| Style |
|
Strap |
| Compatible U-Joint Kits |
|
SPI-5-153X,SPI-5-785X,SPI-5-810X |
| U-Bolt or Strap Assembly |
|
SPI-2-70-18X |
| Bare Yoke part number (if assembly - included) |
|
SPI-2-4-7491-1 |
| Slinger Part Number (if assembly - included) |
|
SPI-231579 |
| Notes |
|
Coupling shaft yoke |
| Cast/Forged |
|
|
|
| |
|
