Spicer 2-4-8241
|
| |
|
Quantity in Basket:
None
Code: SPI-2-4-8241
Price: $150.35
1 In Stock
|
| |
End Yoke - Splined Bore
1310 series, Snap Ring Style, Ø1.010x15 spline, Ø2.120 hub diameter
|
This part is a member of the following categories:
Search by Category * End Yokes * Splined Bore * 15 Splines * Ø1.010 - 15 Involute
| U-Joint Series |
|
1310 |
| Spline Major Diameter |
|
1.010 |
| Spline Count |
|
15.000 |
| Spline Type |
|
Involute |
| Spline Pressure Angle |
|
|
| Ground Hub Diameter |
R |
2.120 |
| Length Thru Bore |
Q |
1.470 |
| Centerline of Joint to End of Spline |
S |
2.500 |
| Universal Joint Retaining Width |
E |
3.469 |
| Universal Joint Bearing Diameter |
D |
1.062 |
| Counterbore Depth |
|
0.000 |
| Joint Angle |
|
0.000 |
| Style |
|
Snap Ring |
| Compatible U-Joint Kits |
|
SPI-5-153X,SPI-5-1310X,SPI-5-1310-1X |
| U-Bolt or Strap Assembly |
|
Not used |
| Bare Yoke part number (if assembly - included) |
|
|
| Slinger Part Number (if assembly - included) |
|
|
| Notes |
|
.375 Diameter set screw. Hub diameter not ground |
| Cast/Forged |
|
|
