Spicer 3-4-24-1
|
| |
|
Quantity in Basket:
None
Code: SPI-3-4-24-1
Price: $80.61
|
| |
End Yoke - Tapered Bore
1350 series, 1.375 Bore w/0.375 keyway, Ø2.250 hub diameter
|
This part is a member of the following categories:
Search by Category * End Yokes * Tapered Bore
| General Design Type |
|
Tapered Bore |
| U-Joint Series |
|
1350 |
| Bore Diameter |
P |
1.375 |
| SAE Keyway Width |
X |
0.375 |
| Hub Diameter |
R |
2.250 |
| Universal Joint Retaining Width |
E |
3.625 |
| Universal Joint Bearing Diameter |
D |
1.188 |
| Length Thru Bore |
Q |
2.000 |
| Centerline of Joint to End of Hub |
S |
3.531 |
| Set Screw Thread |
|
0.000 |
| Keyway Location |
|
|
Set Screw Location
Clock position viewed at Hub End and Keyway at 12 |
W |
|
| Joint Angle |
|
0.000 |
| Style |
|
Strap |
| Compatible U-Joint Kits |
|
SPI-5-178X,SPI-5-799X |
| U-Bolt or Strap Assembly |
|
SPI-3-70-28X |
| Notes |
|
|
| Cast/Forged |
|
|
|
| |
|
