Spicer 3-4-2851-1X
|
| |
|
Quantity in Basket:
None
Code: SPI-3-4-2851-1X
Price: $89.42
|
| |
End Yoke Assy - Splined Bore
1410 series, Strap Style, Ø1.375x10 spline, Ø1.719 hub diameter
|
This part is a member of the following categories:
Search by Category * End Yokes * Splined Bore * 10 Splines * 1.375 - 10 Spline
| U-Joint Series |
|
1410 |
| Spline Major Diameter |
|
1.375 |
| Spline Count |
|
10.000 |
| Spline Type |
|
|
| Spline Pressure Angle |
|
|
| Ground Hub Diameter |
R |
1.719 |
| Length Thru Bore |
Q |
1.781 |
| Centerline of Joint to End of Spline |
S |
3.469 |
| Universal Joint Retaining Width |
E |
4.188 |
| Universal Joint Bearing Diameter |
D |
1.188 |
| Counterbore Depth |
|
0.000 |
| Joint Angle |
|
30.000 |
| Style |
|
Strap |
| Compatible U-Joint Kits |
|
SPI-5-160X,SPI-5-801X |
| U-Bolt or Strap Assembly |
|
SPI-3-70-28X |
| Bare Yoke part number (if assembly - included) |
|
SPI-3-4-2841-1 |
| Slinger Part Number (if assembly - included) |
|
SPI-98-1473 |
| Notes |
|
Hub diameter not ground. |
| Cast/Forged |
|
|
Known Idenfiying Marks (Casting/Forging numbers, etc.):
| | Mark | | Location |
| |
489-1
| |
cast into bottom of yoke ear |
| |
3-2841-1
| |
pin etched into side of yoke ear |
|
| |
|
