Neapco N3R-3-9170KX

Neapco N3R-3-9170KX Quantity in Basket: None
Code: NEA-N3R-3-9170KX
Price: $106.15


Quantity:

Slip Yoke
3R series, 1.375x16 spline
7.375 Centerline to End



This part is a member of the following categories:

Search by Category * Driveshaft Components * Slip Yokes * 1.375 - 16 Spline


General Design Type     LD-MD Driveshaft
U-Joint Series     3R
Spline Major Diameter     1.375
Spline Count     16.000
Spline Type     Parallel
Max Joint Angle     0.000
Universal Joint Retaining Width   E   2.563
Universal Joint Bearing Diameter   D   1.125
Centerline of Joint to End of Spline   J   7.375
Centerline of Joint to Face of Plug   F   1.360
Part Number of Lube Fitting     NEA-0641-B
Dust Cap & Washer Kit Number     NEA-280194
Slip Yoke Plug part number (included)
Boot Kit Assembly part number (order separately)
Compatible U-Joint Kits     SPI-5-3147X,SPI-5-795X
Style     Snap Ring
Notes




This part contains the following parts:

NEA-0641-B - Grease Fitting
NEA-280194 - Drive Shaft Dust Seal



Related Item(s)



Spicer 5-3147X Spicer 5-3147X
Code: SPI-5-3147X
Price: $20.73
In Stock
Quantity in Basket: none
U-Joint - Inside Snap Rings
MECHANICS S44 Series, Greasable





Spicer 5-795X Spicer 5-795X
Code: SPI-5-795X
Price: $29.26
In Stock
Quantity in Basket: none
U-Joint - Inside Snap Rings
SPICER SPL25/S44 Series, Non-Greasable
Spicer Life Series
Replacement Bearing Seal Protector = SPI-232976-2T
