Powertrain Industries 3104-30
|
| |
|
Quantity in Basket:
None
Code: PTI-3104-30
Price: $78.06
|
| |
End Yoke - Splined Bore
1310 series, U Bolt Style, Ø1.312x30 spline, Ø1.940 hub diameter
|
This part is a member of the following categories:
Search by Application * Axles * GM * 8.5" / 8.625"
Search by Application * Axles * GM * 9.5"
Search by Category * End Yokes * Splined Bore * 30 Splines * 1.312 - 30 Involute
| U-Joint Series |
|
1310 |
| Spline Major Diameter |
|
1.312 |
| Spline Count |
|
30.000 |
| Spline Type |
|
Involute |
| Spline Pressure Angle |
|
|
| Ground Hub Diameter |
R |
1.940 |
| Length Thru Bore |
Q |
1.150 |
| Centerline of Joint to End of Spline |
S |
3.160 |
| Universal Joint Retaining Width |
E |
3.219 |
| Universal Joint Bearing Diameter |
D |
1.062 |
| Counterbore Depth |
|
0.000 |
| Joint Angle |
|
0.000 |
| Style |
|
U Bolt |
| Compatible U-Joint Kits |
|
SPI-5-153X,SPI-5-785X,SPI-5-810X |
| U-Bolt or Strap Assembly |
|
SPI-2-94-28X |
| Bare Yoke part number (if assembly - included) |
|
|
| Slinger Part Number (if assembly - included) |
|
|
| Notes |
|
|
| Cast/Forged |
|
|
|
| |
|
