This part's status is Obsolete
.
*** Please call or e-mail us. These may still be available as surplus parts. ***
|
Spicer 2-1-1871
|
| |
|
Quantity in Basket:
None
Code: SPI-2-1-1871
Price: $190.08
Obsolete
|
| |
Companion Flange - Splined Bore
1310 series, Ø1.146x26 spline, Ø1.554 hub diameter
4xØ.375 Holes on 3.125 BC, Ø2.375-F pilot, Ø1.554 hub diameter
|
| U-Joint Series |
|
1310 |
| Spline Major Diameter |
D |
1.146 |
| Spline Count |
|
26.000 |
| Spline Type |
|
Involute Spline |
| Pilot Bore Diameter |
C |
2.375-F |
| Bolt Circle Diameter |
B |
3.125 |
Bolt Circle Hole Diameter
(D = Drilled, T = Tapped) |
|
.375 D |
| Number of Holes |
|
4.000 |
| Brake Pilot Diameter |
|
2.550 |
| Ground Hub Diameter |
E |
1.554 |
| Length Thru Bore |
F |
1.500 |
| Flange Face to End of Hub |
G |
2.594 |
| Bare Flange Part Number (if assembly) |
|
SPI-2-1-1871 |
| Slinger Part Number (if assembly) |
|
SPI-15099 |
| Notes |
|
|
This part is used in the following assemblies or kits:
SPI-2-1-1881X - Companion Flange - Splined Bore
