Northern Drivetrain 00155

Northern Drivetrain 00155 Quantity in Basket: None
Code: NDT-00155
Price: $147.00

10 In Stock



Quantity:

Companion Flange - Splined Bore
1410 series, 1.750x10 spline, 2.375 hub diameter
4 Drilled Holes on 4.750BC, 3.750-F pilot


The following parts may be used as alternates for this part:

Ouverson Engineering and Machine 2101

This part is a member of the following categories:

Search by Application * Transfer Cases * Pro-Fab
Search by Application * Transfer Cases * SCS
Search by Category * Companion Flanges * Splined Bore * 10 Splines * 1.750 - 10 Spline


U-Joint Series     1410/1480/1550
Spline Major Diameter   D   1.750
Spline Count     10.000
Spline Type     Spline
Pilot Bore Diameter   C   3.750-F
Bolt Circle Diameter   B   4.750
Bolt Circle Hole Diameter
(D = Drilled, T = Tapped)
  .506 D
Number of Holes     4.000
Brake Pilot Diameter     0.000
Ground Hub Diameter   E   2.375
Length Thru Bore   F   2.200
Flange Face to End of Hub   G   2.500
Bare Flange Part Number (if assembly)
Slinger Part Number (if assembly)
Notes
