*** BW4464 Fixed Rear 37 spline ***
|
Northern Drivetrain 00267
|
| |
|
Quantity in Basket:
None
Code: NDT-00267
Price: $223.14
1 In Stock
|
| |
Companion Flange - Splined Bore
1330 series, Ø1.523-37 spline
4xØ0.413 Tapped Holes on 4.25BC, Ø3.125-M pilot
|
This part is a member of the following categories:
Search by Application * Search by Transfer Case * Borg Warner * 4464
| U-Joint Series |
|
1330 |
| Spline Major Diameter |
D |
1.523 |
| Spline Count |
|
37.000 |
| Spline Type |
|
Involute Spline |
| Pilot Bore Diameter |
C |
3.125-M |
| Bolt Circle Diameter |
B |
4.250 |
Bolt Circle Hole Diameter
(D = Drilled, T = Tapped) |
|
.438 T |
| Number of Holes |
|
4.000 |
| Brake Pilot Diameter |
|
0.000 |
| Ground Hub Diameter |
E |
1.974 |
| Length Thru Bore |
F |
2.725 |
| Flange Face to End of Hub |
G |
3.010 |
| Bare Flange Part Number (if assembly) |
|
|
| Slinger Part Number (if assembly) |
|
|
| Notes |
|
Square bolt pattern, Fits NP205 with ProFab 35 spline output shaft |
|
