Spicer 1-2-39

Spicer 1-2-39 Quantity in Basket: None
Code: SPI-1-2-39
Price: $43.92

1 In Stock



Quantity:

Flange Yoke
1100 series, 4x.312 Holes on 2.750BC, 2.250M pilot



This part is a member of the following categories:

Search by Category * Flange Yokes * Other Sizes


Design Style     Snap Ring Design
U-Joint Series     1100
Universal Joint Retaining Width     2.656
Universal Joint Bearing Diameter   D   0.938
Flange Diameter   A   3.375
Bolt Circle Diameter   B   2.750
Horizontal Distance Between Holes (center to center)     0.000
Vertical Distance Between Holes (center to center)     0.000
Bolt Hole Diameter     .312-D
Bolt Hole Quantity     4.000
Pilot Diameter (M-Male, F-Female)   C   2.250M
Centerline of Joint to Flange Face   G   1.188
Compatible U-Joint Kits     SPI-5-101X,SPI-5-111X
    0.000
Notes
Cast/Forged


This part is used in the following assemblies or kits:

SPI-201060-8 - DRIVESHAFT
SPI-8297-SF - DRIVESHAFT
SPI-8297-SF - DRIVESHAFT
SPI-903997-1 - DRIVESHAFT S.C.




Related Item(s)



Spicer 5-101X Spicer 5-101X
Code: SPI-5-101X
Price: $22.18
In Stock
Quantity in Basket: none
U-Joint - Outside Snap Rings
SPICER 1100 Series, Non-Greasable
