Spicer 10-4-183

Spicer 10-4-183 Quantity in Basket: None
Code: SPI-10-4-183
Price: $50.94

1 In Stock



Quantity:

End Yoke - Round Bore
1000 series, 1.250 Bore w/0.25 keyway, 2.000 hub diameter


The following parts may be used as alternates for this part:

Neapco 10-4183
Rockwell/Meritor 10N-4-183

This part is a member of the following categories:

Search by Category * End Yokes * Round Bore


General Design Type     Round Bore
U-Joint Series     1000
Bore Diameter   P   1.250
SAE Keyway Width   X   0.250
Hub Diameter   R   2.000
Universal Joint Retaining Width   E   1.500
Universal Joint Bearing Diameter   D   0.938
Length Thru Bore   Q   1.030
Centerline of Joint to End of Hub   S   2.500
Set Screw Thread     0.375
Keyway Location     9
Set Screw Location
Clock position viewed at Hub End and Keyway at 12
W   12
Joint Angle     0.000
Style     Inside Snap Ring
Compatible U-Joint Kits     SPI-5-170X,SPI-5-110X
U-Bolt or Strap Assembly
Notes     High angle yoke
Cast/Forged     Cast






Related Item(s)



Spicer 5-110X Spicer 5-110X
Code: SPI-5-110X
Price: $26.88
In Stock
Quantity in Basket: none
U-Joint - Inside Snap Rings
SPICER 1000 Series, Non-Greasable





Spicer 5-170X Spicer 5-170X
Code: SPI-5-170X
Price: $18.60
In Stock
Quantity in Basket: none
U-Joint - Inside Snap Rings
SPICER 1000 Series, Greasable
