Northern Drivetrain 00103
|
| |
|
Quantity in Basket:
None
Code: NDT-00103
Price: $101.52
5 In Stock
|
| |
Tube Yoke
1410 series, Ø2.000 X .120 W tube
|
This is a Spicer tube yoke modified to fit 2" .120 wall driveshaft tubes common in the front driveshafts of 4x4 applications. It is also useful in buggy and other tight clearance applictions, if you do not have much room to fit a driveshaft through your frame or past other obstructions.
This part is a member of the following categories:
Search by Category * Driveshaft Components * Tube Yokes * 1410
| U-Joint Series |
|
1410 |
| Universal Joint Retaining Width |
E |
4.188 |
| Universal Joint Bearing Diameter |
D |
1.188 |
| Yoke Width across Yoke Ears |
W |
4.438 |
| Compatible U-Joint Kits |
|
SPI-5-160X,SPI-5-1410X |
| General Design Type |
|
Steel |
| Tube Diameter and Wall Size |
|
2.000 X .120 W |
| Butt Diameter |
F |
1.864 |
| Centerline of Joint to Point of Weld |
H |
0.000 |
| Joint Angle |
|
25.000 |
| Used in Tube Yoke and Yoke Assembly |
|
|
| Notes |
|
|
| |
|
|
