*** 6 bolt holes, Used to replace CV joints with ujoint style shaft ***


Powertrain Industries 3102-391

Powertrain Industries 3102-391 Quantity in Basket: None
Code: PTI-3102-391
Price: $36.50

1 In Stock



Quantity:

Flange Yoke
1310 series, 6x0.415 Holes on 3.386BC, 3.935 OD pilot





Design Style     Snap Ring Design
U-Joint Series     1310
Universal Joint Retaining Width     3.469
Universal Joint Bearing Diameter   D   1.062
Flange Diameter   A   0.000
Bolt Circle Diameter   B   3.386
Horizontal Distance Between Holes (center to center)     0.000
Vertical Distance Between Holes (center to center)     0.000
Bolt Hole Diameter     0.415-D
Bolt Hole Quantity     6.000
Pilot Diameter (M-Male, F-Female)   C   3.935 OD
Centerline of Joint to Flange Face   G   2.592
Compatible U-Joint Kits     SPI-5-153X,SPI-5-1310X,SPI-5-1310-1X
    0.000
Notes     6 bolt holes, Used to replace CV joints with ujoint style shaft
Cast/Forged
