Spicer 3-4-6631-1X

Spicer 3-4-6631-1X Quantity in Basket: None
Code: SPI-3-4-6631-1X
Price: $58.74

1 In Stock



Quantity:

End Yoke Assy - Splined Bore
1410 series, Strap Style, 1.500x10 spline, 1.812 hub diameter



This part is a member of the following categories:

Search by Category * End Yokes * Splined Bore * 10 Splines * 1.500 - 10 Spline


U-Joint Series     1410
Spline Major Diameter     1.500
Spline Count     10.000
Spline Type     parallel
Spline Pressure Angle     n/a
Ground Hub Diameter   R   1.812
Length Thru Bore   Q   2.000
Centerline of Joint to End of Spline   S   3.719
Universal Joint Retaining Width   E   4.188
Universal Joint Bearing Diameter   D   1.188
Counterbore Depth     0.000
Joint Angle     0.000
Style     Strap
Compatible U-Joint Kits     SPI-5-160X,SPI-5-1410X
U-Bolt or Strap Assembly     SPI-3-70-28X
Bare Yoke part number (if assembly - included)     SPI-3-4-6561-1
Slinger Part Number (if assembly - included)     SPI-231004
Notes     Coupling shaft yoke - hub diameter not ground
Cast/Forged



This part contains the following parts:

SPI-3-4-6561-1 - End Yoke - Splined Bore --
SPI-231004 - Slinger --



Related Item(s)



Spicer 231004 Spicer 231004
Code: SPI-231004
Price: $1.92
In Stock
Quantity in Basket: none
Slinger
3.656 OD x 2.141 ID x 0.438 Wide





Spicer 3-4-6561-1 Spicer 3-4-6561-1
Code: SPI-3-4-6561-1
Price: $44.95
Normally drop ships in 1-3 business days
Quantity in Basket: none
End Yoke - Splined Bore
1410 series, Strap Style, 1.500x10 spline, 1.812 hub diameter





Spicer 3-70-28X Spicer 3-70-28X
Code: SPI-3-70-28X
Price: $6.44
In Stock
Quantity in Basket: none
Bearing Strap
Fits 1350/1410 U-Joints





Spicer 5-1410X Spicer 5-1410X
Code: SPI-5-1410X
Price: $32.81
In Stock
Quantity in Basket: none
U-Joint - Outside Snap Rings
SPICER 1410 Series, Non-Greasable
Spicer Life Series





Spicer 5-160X Spicer 5-160X
Code: SPI-5-160X
Price: $25.30
In Stock
Quantity in Basket: none
U-Joint - Outside Snap Rings
SPICER 1410 Series, Greasable
